60T BROWN & BOGGS 17-1/2 LJA FLYWHEEL OBI PUNCH PRESS

Manufacturer
BROWN & BOGGS

Type
Presses, Gap Frame, Single Crank

Model
17-1/2 LJA

Stock #
9287

Condition
Used

Year
Not Specified

Request a Quote

Specifications

Max. Capacity

60 tons

Strokes per Minute

86 SPM approx.

Stroke

5 inches

Shut Height

12.375 inches

Ram Adjustment

3 inches

Bed Size (L-R x F-B)

32" x22.5"

Ram Area L-R x F-B

21" x16" flanged

Throat Depth

11.250 inches

Shank Hole Dia

2 inches

Width of opening thru frame

15 inches

Distance bed to floor

33.5 inches

Main Motor

5 HP MAIN, 575/460/3/60

Weight (Approx)

10600 lbs.

Dimensions, approx

79”x63”x112”

Equipped With

Features:

Air Clutch and Brake,
Flush Floor Design
Heavy Duty
Open Back Inclinable
Flywheel Drive

EQUIPPED WITH:

* Filter / Regulator / Lubricator

* STI Safety Light Curtains, 24”

* Upgraded Control “MHD Engineering Control”

* Dual Ross Valve

* Automatic Lubrication

* Bolster Plate, 24” x 48” x 1 3/4”

* Hand Push Palm Buttons, Start/Stop

* Air Counter balance

* Ram Block

* Physical Barrier Guarding

* LOX Valve

* Crankshaft Safety Hook
