BRANDT 3R Series Model 3R-21 (21Ton) Three Die Cylindrical Thread Rolling Machine

Manufacturer
Not Specified

Type
Threading Machines, Thread Rollers, Planetary Die

Model
3R Series

Stock #
NEW

Condition
Used

Year
Not Specified

Request a Quote

Specifications

Equipped With

> The 3R series of hydraulic rolling machines
are equipped with three rolling spindles, &
with three moving heads.

> All machines equipped with AC Drives.

> Automation, PLC/CNC options are available.

> The machine have radial die loads, ranging from 3-60 Ton (30 to 600 kN)

> The 3R series machines are particularly suitable
for plunge or thru-feed rolling operations on both
hollow and solid components.

Rolling Force (kN): 10-210
Speed Range (rpm): 25-85
Min-Max Die Dia (mm): 110-175
Die Spindle Dia (mm): 54 (69.85)
Max Die Length (mm): 100
Workpiece Dia (mm): 12-90 (65)
Max Pitch (mm): 5
Swivel Angle: +/- 8Deg
Main Motor (kW): 15
Total Power (kW): 19.3
Weight (kgs): 2500
