IZPE 602H 60T 2DIE CYLINDRICAL THREAD ROLLER

Manufacturer
IZPE

Type
Threading Machines, Thread Rollers, Cylindrical Die

Model
602H

Stock #
8848

Condition
Used

Year
1985

Request a Quote

Specifications

Equipped With

Max. Threading Diameter: 5" (127mm)
Maximum Plunge (Infeed) Threading Length: 10" (243mm)
Min. - Max. Threading Pitch: 2 .5 T.P.I. - 26 T.P.I.
Maximum Thread Diameter (Thru-Feed): --
Max. Outside Diameter of Rollers: 9-7/8" (250.8mm)
Min. Outside Diameter of Rollers: 6" (152.4mm)
Rollers Holding Spindle Diameter: 5" (127mm)
Main Power: 25.25hp (19kW)
Maximum Working Pressure: 60tons
Net Weight: 13,200 Lbs. 6,000 Kg.)

Location: Europe
