REED A22HB THREE DIE CYLINDRICAL THREAD ROLLING MACHINE

Manufacturer
REED

Type
Threading Machines, Thread Rollers, Cylindrical Die

Model
A22HB

Stock #
9061

Condition
Used

Year
Not Specified

Request a Quote

Specifications

Maximum Thread Diameter

3.750 inches

Minimum Thread Diameter

.156 inches

Thread Dia Thru Feed, Max

1 inches

Thread Length Thru Feed, Min

.250 inches

Thread Length Infeed

2.375 inches

Thread Length Thru Feed

11 inches

Max. Die Diameter

4 inches

Weight (Approx)

2500 pounds

Maximum Rolling Force

15 tons

Max Die Width

2.375 inches

Spindle Speeds

108 - 720 RPM

Floor Space approx

46"W x 36"L

Equipped With

Specifications for Diameter & Thread lengths are Infeed only, unless noted otherwise
Die Holders: 30C
