Equipped With
Wire diameter range: 2– 8 mm (14=1/4ga - 4ga)
• Machine adjusted for: 3 - 6 mm (straightening rotor & tools)
* Tensile strength: up to 800 N/mm² (approx 100,000 psi)
• Wire cutting length: 100 - 3500 mm
• Loading capacity per coil: max. 2000 kg/ each
• Switchboard: 400V, 50Hz
• PLC: Siemens S7-1500, new
• Motors: Rexroth, new
• Air supply:
• Pressure: 6 bar • (Dirt and water free, but lightly oiled)
• Cooling water
Machine was all refurbished completely in 2019/2020 by the German firm, "like new".
They were dismantled & strip down, painted, and have all moving parts changes brand new.
Customer project for the machines died out before putting them into production, so have very little to no use since rebuild work.
• Motorized pay off
• Machine support
• Rotative straightening and cutting unit with displaceable pneumatical shear
• Precision measuring unit
• Programmable control
• Control cables
• Cable channels, wire guiding Main data
Product features
* Wire Length: Freely programmable, allowing for individual wire lengths
* Modular Design: The design allows for quick changeovers and adjustments to individual needs, making it adaptable to different production requirements.
Suitable for Wire Materials:
• Smooth wire
• Ribbed wire
• Galvanized wire
• Stainless wire
Designed for integration into mesh welding plants
or to be operated as a stand-alone version.
The Syrocut system comprises a synchronously operating spinner straightening machine, a cutting unit, and a powered coil-off. It can process wire from a coil, spool, or reel, straightening it for use in various applications, including industrial and fencing mesh welding systems.
