Equipped With

* Blade Type Hopper w/chrome plated blade & rail chute * Jaw type spindle * Spindle drive & cam drive inverted controlled * Electric brake on main spindle drive motor * Brake motor, torque clutch & vari-drive pulley on cam drive system * Cam operated loader * Timer controlled feeding into rail chute * Sensor for hopper control * Piece by piece feeding * Front & rear tool slides * Pick off finger * Pressurized automatic lubrication system * Sensor controlled shut off for mis-chucking * Plumbed for turnaround finger * Electrical protection for short circuit & overload * Automatic chain tensioner for cam & vari-drive * Split cam feature * Full steel protective covers * Set of general purpose cams Shank Diameter Range: 0.78? ? 0.625" (2mm ? 16mm) Blank Length Range: .394 ? 2-1/2" (10 - 63.5mm) Spindle Motor Power: 2hp (1.5kW) Chucking Clearance: .561? (14mm) Chucking Opening: 1.18? (30mm) Maximum Spindle Speed-RPM: 1500 ? 1800 Production Rate ? Pcs. per minute: 7 ? 30 ppm Electrics: 220Volts / 3ph / 50-60hz Dimensions (LxWxH): 80.7" x 45.5" x 74.8? (2050x1160x1900mm) Weight (Approx): 3087 Lbs. (1400 Kgs.) Location: N.AMERICAN PLANT
