Wafios Umformtechnik – Nutap UNT20 (3/4″) High Precision High Speed One Spindle Automatic Nut Tapper

Wafios Umformtechnik - Nutap UNT20 (3/4") High Precision High Speed One Spindle Automatic Nut Tapper

Manufacturer
WAFIOS

Type
Nut Tappers

Model
UNT20 (3/4")

Stock #
Not Specified

Condition
New

Year
Not Specified

Request a Quote

Specifications

Type

1-Spindle

Maximum Thread Diameter

.750 inches

Maximum Thread Diameter

20 millimeters

Minimum Thread Diameter

.313 inches

Minimum Thread Diameter

8 millimeters

Biggest Flange or Max. Outside Dia.

50 millimeters

Max. Length of Parts

150 millimeters

Max. Machining Depth

70 millimeters

Max. spindle traverse

140 millimeters

Production Rate

55ppm (Standard hex nut)

Power of spindle motor

6.9 kW

Equipped With

Features:
* Tapping, Boring & Counter-boring of Special Nuts
* Specially Suited to Thread Blind Borings & Extremely Long Parts
* PLC Control & Process Tap Monitoring
* Full Electronically Control of Indexing Plate, Feeding and Tapping
* Cutting Feed via Clearance-Free Re-circulating Ball Spindle
* Adjustable Magazines
* Spindle & Roller Bearings with Lifetime Lubrication
* Automatic Transport of Chips

Downloads

Nutap UNT.pdf
