ABBEY ETNA 2-DIE ROTARY SWAGER

Manufacturer
ABBEY ETNA

Type
Swagers

Model
Not Specified

Stock #
8866

Condition
Used

Year
Not Specified

Request a Quote

Specifications

Equipped With

Complete Electrical Controls
Complete Coolant System
1 Set of Dies

Capacity-Tubing, mild steel: 2-1/2"
Capacity-Solid, mild steel: 1-1/4"
No of Dies: 2
Die Width: 3"
Die Thickness: 2 1/2"
Die Length: 7"
Number of Rolls: 12
Roll Diameter: 2"nomnal
Spindle Speed: 300 RPM (est.)
Blows per Minute: 3,600 (est.)
Height to Spindle Centerline: 34" (nominal)
Main Drive Motor: 20 HP @ 1,800 RPM
Electrics: 220/440 VAC / 3 Phase / 60 Cycle
Overall Dimensions: 42" L-R x 59" F-B x 60" High (est.)
Weight: 4,990 lbs. (palletized.)

Location: N.AMERICA
