Equipped With
Double Knife Shearing Method
Fingerless Transfer System
Positive Knockout -Second & Third Punches
Knock out relief device
Positive Interlocked lub system on all critical areas
Eddy-Current variable speed drive motor w/production rate indicator
Automatic parts counter w/pre-set device for machine shutoff
Machine completely enclosed
Positive full-length blank cutoff on shut down
Maximum Cutoff Diameter (@99,800 PSI): .394" (10mm)
Maximum 1st Die Kickout: 6.300" (160mm)
Max. 2nd Die Kickout: 3.149" (80mm)
Maximum Cutoff Length: 4.000" (100mm)
2nd Punch Kickout: 1.378" (35mm)
3rd Punch Kickout: .394" (10mm)
Production Speed: 50-100 ppm
Main Motor: 30hp (22kW)
Net Weight: 33,200 lbs (15,000 kgs)
Location: N AMERICAN PLANT
