WHITELEGG CFM-1000E-TWR Twin Axis Universal 2D CNC Wire Forming & Welding Machine

Manufacturer
WHITELEGG

Type
Wire Machinery, Forming

Model
CFM-1000E-TWR

Stock #
9091

Condition
Used

Year
2006

Request a Quote

Specifications

Maximum Wire Diameter

.394 inches

Maximum Wire Diameter

10 millimeters

Minimum Wire Diameter

.120 inches

Minimum Wire Diameter

3 millimeters

Maximum Ring Diameter

60" [1500 mm]

Maximum Frame Size

60" X 60" (1500x1500 mm)

Maximum Bend Speed

720/S

Production Rings Welded

15/MIN (150-1000mm)

Production Frames

8-14/Min : Min 150x150mm, Max1500X1500mm

Equipped With

Features:

* Double bend heads

* "E" Extended frame model

* Automatic Butt Welding Unit

* Twin Plane Roller Straightener

* Custom Built Power Driven Wire Decoiler

**Spare drive

**10-16 sets of feed rollers for .128"-.250" diameters
